DE12 D2366 Enginetech Piston Rings 65.02503-8236 For DOOSAN

Ask Lasest Price
Brand Name :	HDPARTS
Model Number :	DE12 D2366
Price :	Looking forward to your inquiry
Payment Terms :	T/T, Western Union, MoneyGram,HSBC
Supply Ability :	1000 Piece/Pieces per Month
Delivery Time :	2-5 work days

Add to Cart

Product Details
Company Profile

DE12 D2366 Enginetech Piston Rings 65.02503-8236 For DOOSAN

DE12 D2366 Piston Ring 65.02503-8236 Suitable For DOOSAN Diesel Engines Parts

Specification

Applicable models	DE12 D2366
Type	Piston ring
Original number	65.02503-8236
Warranty	6 months
Engine Type	Diesel
Brand Name	HDPARTS
Condition	New
Size	OEM Size

Piston ring usage

The working surface of the piston ring shall not be nicked, scratched or peeled off. The outer cylindrical surface and the upper and lower end faces shall have a certain finish. The curvature deviation shall not be greater than 0.02-0.04 mm. The standard settlement of the ring in the groove shall not exceed 0.15-0.25 mm. The elasticity and clearance of the piston ring shall meet the requirements

Precautions for piston ring

When installing the piston ring, pay attention to:

1) The piston ring shall be installed into the cylinder liner, and there shall be certain opening clearance at the interface.

2) The piston ring shall be installed on the piston, and there shall be certain side clearance in the ring groove along the height direction.

3) The chrome plated ring shall be installed in the first pass, and the opening shall not face the vortex pit on the top of the piston.

4) The openings of each piston ring shall not face the piston pin hole when they are staggered by 120 ℃.

5) The conical section piston ring shall be installed with the conical surface upward.

6) Generally, when installing the torsion ring, the chamfer or groove shall be upward; When installing the conical anti twist ring, keep the conical surface upward.

7) When installing the combined ring, install the axial lining ring first, then the flat ring and the wave ring. A flat ring shall be installed on the top and bottom of the corrugated ring, and the openings of each ring shall be staggered.

Product Description

Company Information

Guangzhou Hdparts Co., Ltd.

Founded in 1995, we are a company specializing in engine parts for construction machinery (excavators, loaders, bulldozers, heavy trucks, forklifts and other series of construction machinery). Main cylinder block, cylinder head, crankshaft, overhaul kit,piston, cylinder liner, piston ring, size tile, camshaft, connecting rod, oil pump, water pump, valve series products
